LED Light Bars




LED LIGHT BAR 350 • 408 x 57 x 67mm (including bracket) • Spread and Spot beam options • 2200 Lumen Output • 840g	→ High Performance LEDs → Low profile design → Easy to clean housing → Road legal with ECE approval → Designed and manufactured in New Zealand → 5 year warranty	LED LIGHT BAR 470 • 528 x 57 x 67mm (including bracket) • Spread/Spot - 2800 Lumen • Combi - 2200 Lumen • Diffused - 3600 Lumen • 950g



	Unique Corrosion Proof Housing Providing unmatched corrosion resistance due to an innovative thermally conductive polymer housing. This advanced material draws heat from internal electronics for reliable long-term operation and eliminates the need for aluminium housing, removing corrosion risks in harsh environments.		Tough Grilamid^® Lens Grilamid^® offers an unbeatable combination of properties including toughness against impact, long term UV stability and resistance to commonly used chemicals and washes. Grilamid^® will not lose its lustre or embrittle over time but will remain clear, transparent and impact tough for the life of the product.




	Flexible mounting options The light weight means less stress on mounting locations, and a versitile bracket means aiming the light is a simple affair.		Number Plate Mounting Brackets These mounting brackets allow you to quickly and easily mount your 350 or 470 light bar, either upright or pendant.



	Quality and Warranty All LED Light Bars are designed and manufactured in New Zealand, completely sealed against dust and water and carry a 5 year warranty. LED Light Bars are the natural choice when exceptional durability and long term reliability in demanding environments are needed.		P/N 8HG 958 128-811 Accessory An optional double bracket enables you to stack multiple lamps to increase the light output or spread of light.

		Available at all leading auto electrical outlets nationwide
click for more LED LIGHT BAR 350	click for more LED LIGHT BAR 470	Find Your Nearest Stockist HERE


LAMP SPECIFICATIONS


	LED LIGHT BAR 350	LED LIGHT BAR 470




SIZE	408 x 57 x 67mm (including bracket)	528 x 57 x 67mm (including bracket)
LENS OPTIONS	SPREAD	SPREAD


	SPOT	SPOT


		COMBI


		DIFFUSE


HOUSING COLOURS	Black, White	Black, White
OUTPUT	Spread/Spot: 2200 Lumen	Spread/Spot: 2800 Lumen
		Combi: 2200 Lumen
		Diffused: 3600 Lumen
COLOUR TEMP	5000K (white)	5000K (white)
WEIGHT	840g	950g
HOUSING MATERIAL	"Non Metal" Thermally conductive polymer	"Non Metal" Thermally conductive polymer
LENS MATERIAL	Heavy Duty Grilamid	Heavy Duty Grilamid
BRACKET MATERIAL	Polished 316 Stainless Steel	Polished 316 Stainless Steel
POWER CONSUMPTION	High: 25W	Combi High: 36W
	Low: 5W	Spread/Spot: 18W
		Low: 4W
OPERATING VOLTAGE	Multivolt™ 9-33V DC	Multivolt™ 12/24V DC
PROTECTION	IP6K7/IP6K9K Completely Sealed	IP6K7/IP6K9K Completely Sealed
CABLE LENGTH	Pre-wired - 2.5m triple core marine cable	Pre-wired - 2.5m triple core marine cable
COMPLIANCE/APPROVAL	CE, RCM	CE, RCM
WARRANTY	5 years	5 years


LED LIGHT BAR 350		LED LIGHT BAR 470


	Available at all leading auto electrical outlets nationwide.		FIND YOUR NEAREST STOCKIST HERE
